Gas Leak Detection Solutions
Identify and quantify more fugitive emissions, faster.
Work with Montrose Environmental to bring the power of LDAR Opgal cameras to your LDAR program for accurate gas leak detection solutions.
Our team is proficient in operating each model of Opgal EyeCGas™ 2.0 camera. Whether you’re testing for Volatile Organic Compounds (VOC’s), CO2, CO, or Methane gases, we have a camera and a team that can support you.
Plus, Opgal’s EyeCSite™ enables quantification based on VOC emissions image processing through proprietary software.
Key Specs
- VOC Emissions Detection & Quantification
- Intrinsically Safe Certified
- EPA 0000a & AWP Compliant
- Thermographic Imaging
- Integrates with various LDAR software and analyzers
- IECEX intrinsically safe Zone II, ANSI, CSA Class I, and Class II Div. 2
- Quantification via EyeCSite software or 3rd party devices
- 4+ Hour Battery Field Operation
- Wireless connectivity
- Glare Shield
- Built-in GPS
- Supplied Accessories include: Batteries (2), Battery Charger, USB Cable, Neck Strap, Glare Shield, Carrying Case, Cleaning Kit.
- 4 Year Warranty
- Cooled cameras can identify midinfrared VOC’s, CO & CO2
- Uncooled cameras can identify highly concentrated methane
- Opgal platforms can be integrated as continuous emissions monitoring systems and provide quantification
- Ergonomically preferred glare shield viewing
- Manufacturer 4 year Warranty included
- Includes 64GB storage
- Video streaming to external phone or tablet
- Quantification PPM streaming from industry standard FID analyzer
- No annual maintenance or calibration required
- Optional operator certification training, on-site, through Montrose
Imaging Performance
| Thermal Sensitivity | <12mK@ 25˚C |
| Optics | f/1.1; 18° with 30mm lens; Manual focus |
| Digital Zoom | x2, x4, x8 and x16 (only for visible camera) |
| Embedded Digital Camera | HD, fixed focus, for situational awareness |
Detector
| Type | Cooled High Sensitivity, 320 x 240 pixels |
| Spectral Range | 3 to 4.4µm |
Gas Leak Detection Performance
| Operation Features | Auto and Enhanced Modes |
| With Spectral Filter of 3.2uM to 3.4uM | For detection of VOCs gases |
Digital Video and Audio Recording
| Video and Audio Recording | Digital video recorder build-in generates a .ts format video on all modes |
| Snapshot Capabilities | Snapshot command generates a .jpg file on any of the available modes |
| Storage | Up to 20 hours and more of video storage over a 64GB solid state memory |
Communication Interfaces
| USB | Data transfer, video streaming and video images file transfer |
| Wi-Fi | 2.4 GHz for video streaming and file transfer |
| Bluetooth | Bluetooth 4.2 with other devices: RMLD, TVA2020, LDAR software etc. |
| GPS | Built-in or external |
Communication Interfaces
| Power | 12 VDC; 13W |
| Battery Life | >4.5 hours continuous operation |
Physical Characteristics
| Weight (with Battery & Lens) | 2.6kg (5.9 lbs) |
| Color | Grey and Black |
| Size IN (LxHxW) | 9” x 4.3” x 5.1” (230 x 110 x 130) mm |
| Interface | Tripod mounting UNC 1/4”, rotation safe |
| Display | 3.5” Color LCD 640X480 |
Themography
| Measurement | Spot temperature measurement |
| Range | -20°C to +350 °C |
| Accuracy | At Least ± 1 °C (0 – 100 °C), ± 2% (> 100 °C), ± 2°C (-20 – 0 °C) |
| Color Palettes | 6 color palettes (Rainbow, Iron, ISO red, ISO green, Grey Scale and Vivid) |
Quantification
| Gas Quantification | Image processing VOC gas quantification for desktop or handheld application (offline/ online operation) |
Environmental Conditions
| Operating Temperature Range | -20°C to + 50°C |
| Storage Temperature Range | -40°C to + 70°C |
| Temperature and Humidity | IEC 60068-2-30 Temp. +25°C / +40°C Humidity 95% RH |
| EMC/EMI | EN 60079-0:2012/A11:2013, EN 60079-11:2012, EN 60079- 15:2010, IEC 60079-0:2017, IEC 60079-11:2011,IEC 60079- 15:2010, IEC 60079-31:2013 |
| Vibration | 2.4 GRMS Random Vibration |
| Water and Dust Protection | IP65 |
| High Accelerated Life Test (HALT) | Max temp: 55°C, Min temp: -20°C |
| Safety | EN60950-1:2006 |
| Hazardous Locations Safe | CSA C22.2 No. 213-M1987, Non-Incentive Electrical Equipment for Use in Class I, Division 2, ANSI/ISA-12.12.01 – Class I and II, Division 2, and Class III, ATEX intrinsically safe for Zone 2 ratings as: Ex II 3 GD; Ex ic nA nC IIC T6 Gc; Ex ic tc IIIC T85°C DC |
| Free Fall / Drop Test (In Case) | ASTM-D 4169-06 Schedule A |
| Loose Cargo Vibration Test (In Case) | ASTM-D 4169-08 Schedule F Test method D999 |
| Vibration (In Case) | ASTM-D 4169-08 Schedule F Test method D999 |
Contact Montrose for the environmental solutions you need today—and tomorrow. Send us a message, tell us what you’re interested in, and we’ll get back to you ASAP.
